- Product Introduction
- message
Specifications
| Gas unit model | Electric power | efficiency | ||
| / | @1.0pf | Electrical efficiency | Thermal efficiency | Total efficiency |
| / | KWe | % | % | % |
| CG132-8 | 400 | 42.3 | 45.2 | 87.5 |
| CG132-12 | 600 | 42.0 | 45.8 | 87.8 |
| CG132-16 | 800 | 42.5 | 45.3 | 87.8 |
| CG170-12(K1) | 1000 | 40.0 | 47.0 | 87.0 |
| CG170-12(K) | 1125 | 40.9 | 45.6 | 86.5 |
| CG170-12 | 1200 | 43.6 | 43.3 | 86.9 |
| CG170-16(K) | 1500 | 40.9 | 45.7 | 86.6 |
| CG170-16 | 1560 | 43.2 | 43.8 | 87.0 |
| CG170-20 | 2000 | 43.7 | 43.2 | 86.9 |
| CG260-12 | 3333 | 44.1 | 42.4 | 86.5 |
| CG260-16 | 4300 | 44.1 | 42.7 | 86.8 |
| CG260-16 | 4500 | 44.6 | 41.4 | 86.0 |
| Biogas unit model | Electric power | efficiency | ||
| / | @1.0pf | Electrical efficiency | Thermal efficiency | Total efficiency |
| / | KWe | % | % | % |
| CG132-8 | 400 | 42.8 | 42.0 | 84.8 |
| CG132-12 | 600 | 42.7 | 42.2 | 84.9 |
| CG132-16 | 800 | 42.8 | 42.2 | 85.0 |
| CG170-12 | 1200 | 43.0 | 42.8 | 85.8 |
| CG170-16 | 1560 | 42.6 | 43.1 | 85.7 |
| CG170-20 | 2000 | 43.0 | 43.3 | 86.3 |
| CG260-16 | 3770 | 42.9 | 39.4 | 82.3 |
